Chapter 6. Troubleshooting
44
Street Dash Users Guide
No. Symptom Possible
Cause Remedy
Notes
Lap Marker
Receiver triggered
Turn off Beacon
Switch 4 faulty
Replace switch
Disconnect
the switch
and short the
leads
together. If
the display
changes
replace
Switch 4.
Otherwise
check wiring.
16
Switch 4 does not
reset the trip value
back to zero
Faulty switch wiring
Check switch
wiring for correct
continuity.
Pin U to
yellow S4
wire less
than 1.0
Ohm and Pin
U to Pin H
(ground)
greater than
1M Ohms)
17 External
warning
light dead when
the display
warning light is OK
Bulb has burnt out
Replace bulb
Swap with
the other
light to
confirm
burnt-out
bulb. If not
burnt out,
check wiring.
Faulty wiring to light
Check continuity
of wiring.
Pin G to red
AL wire less
than 1.0
Ohm and Pin
N to yellow
AL wire less
than 1.0
Ohm
Driver
circuitry
burnt out
Return unit
18
External gear shift
light dead
Bulb has burnt out
Replace bulb
Swap with
the other
light to
confirm
burnt-out
bulb. If not,
check wiring
Faulty wiring to light
Check continuity
of wiring:
Pin G to red
SL wire less
than 1.0
Ohm and Pin
M to green
SL wire less
than 1.0
Ohm
