Chapter 3. Operating the Display System
12 Street Dash Users Guide
Displaying the Peak Values
Press and hold Switch 1 to show the peak values for the
parameters being displayed on the current layer. Release the
switch to return to the normal display.
Note: The displayed peak fuel level is the value that was current
when the peak values were last reset. The amount of fuel used
since the peak value reset can be determined by subtracting the
current value from the peak value.
Resetting the Peak Values
You can reset all of the peak values manually. All peak values
are reset at the same time. If the engine is running at or above its
gate value when the peak values are reset, they are set to the
current value of each performance parameter.
To reset the peak values:
• Press and hold Switch 1 to display the peak values.
• While holding Switch 1, press and hold Switch 4.
• With Switch 4 held down, you will see the display revert to
the current values. The new peak values that are stored are
those being displayed when you release Switch 4.
If the engine is running below its gate value, the peak values are
not reset to the current values but are set to the values in the
following table:
Parameter New Peak Value
Engine RPM Current value
Wheel speed Current value
Oil Pressure 999 PSI
Oil Temperature 32F
Water Temperature 32F
Fuel Level Current value
Battery Voltage Current value
Fuel Pressure (optional) High range sensor 999 PSI
Low range sensor 99.9 PSI
