Chapter 6. Troubleshooting
40 Street Dash Users Guide
Chapter 6. Troubleshooting
No. Symptom Possible Cause Remedy Notes
1 Display is dead Ignition is off
Turn ignition on
B + is 19w
connector
pin G.
(no backlight,
nothing on
display, no green
dial lights) Battery is dead Recharge or
replace battery The power
lead B - is
19w
connector
pin H.
Power connection
to B + or B - is
faulty
Check if battery is
connected
correctly. Check
power lead
continuity
2 Display is dead
(no backlight,
nothing on
display, green dial
lights on but dim) Battery is almost
dead Recharge or
replace battery
or
Low Battery
warning on
display Power connection
to B + or B - is
faulty Check power lead
continuity
3 Display flashes
and
Battery is almost
dead Recharge or
replace battery
dial pointer resets
or vibrates Power connection
to B + or B - is
faulty Check power lead
continuity
Pressure sensor
has failed Replace sensor
Sensor
connections are
faulty Check for
continuity on
sensor lead.
A reading of
999 on the
display
indicates an
open circuit
connection
(pin D to the
red sensor
lead and pin
H to the
black sensor
lead)
4 The Low Oil P
message does
NOT appear on
power up.
The warning light
is not turned on.
Oil pressure alarm
disabled Check that the oil
pressure alarm is
set on
