Chapter 3. Operating the Display System
10
Street Dash Users Guide
Display Layer 3
Water MPH Oil P
167 F 135 90
Display layer 3 shows:
• Water temperature
• Current speed (MPH)
• Oil pressure (Oil P)
Display Layer 4
Fuel P MPH Batt
65 135 12.6V
• Fuel Pressure (Fuel P) (optional)
• Current speed (MPH)
• Battery Voltage (Batt)
Display Layer 5
Lap 12 MPH Best
1:35.10 135 1:35.06
Display layer 5 shows:
• Number of the current lap
• Current speed (MPH)
• Last lap time
• Previous best lap time
Lap time can be recorded manually using Switch 4 or with the
optional lap timing kit.
