Auto Meter 6002 - Manual (Page 12)

Chapter 2. Getting Started
6 Street Dash Users Guide
Wiring Harness
Each of the wires in the harness is labeled.
Labels on Short Cables Connection To
S1 to S4 Switches 1 to 4
WS V.S.S. speed input (MPH)
SL Gear shift warning light
AL Alarm warning light
NET Not used
LAP Optional in-car lap timing sensor
Labels on Long Cables Connection To
A Fuel pressure sensor (optional)
ES Engine speed (RPM)
OT Oil temperature sensor
WT Water temperature sensor
OP Oil pressure sensor
F Fuel level sensor
B + Switched 12V Power
B - Battery negative (Chassis) ground
