Table of Programmable Parameters 3.2
38
Busy tone – modulation
Set the busy tone modulation, choosing one of the predefined dialtone patterns.
Setting options: 250/250, 330/330, 200/200, 375/375, 500/500
Default setting: 330/330
Continuous tone – frequency
Set the continuous tone frequency in [Hz]. You can set up to two frequencies for a
dual tone. The continuous tone can be used for setting the Disconnect tone
parameter.
Setting options: 100–3,500 Hz
Setting step: 5 Hz
Default setting: 425 Hz for the first tone, the other tone is disabled.
SLIC > Ringing and CLIP
Frequency
Here set the signal frequency for terminal or PBX ringing in the case of an
incoming GSM call.
Setting options: 10–60 Hz
Setting step: 1 Hz
Default setting: 50 Hz
Modulation
Here set ringing signal modulation, choosing one of the predefined ringing
patterns.
Setting options: 1000/4000, 400/200/400/2000, 1500/3500,2000/4000
Default setting: 1000/4000
CLIP
Set this item to enable sending of a calling GSM line identification. The function
can be enabled if you have a FSK/ETSI receiving device on your telephone line.
Setting options: Disable
2N ® EasyRoute restricts CLI towards the telephone line.
FSK during ringing
2N ® EasyRoute transmits the FSK-based CLI according
to the ETSI EN 300 659 standard during ringing.
Replace ‘+’ by
If this parameter is enabled, the ‘+’ character is replaced with the defined string
in the international prefix of the CLI. It is because the ‘+’ character can neither be
transmitted by the FSK protocol nor dialled in the DTMF format from a terminal.
Setting options: 0–15 characters (0–9, *, #)
