Figure: Terminal Time Synchronisation
The time setting supporting and terminals also display the terminal PRO PRO ETH
time. Click on to set the same time value for the terminal as there is in Synchronize
the server.
Connections
Figure: Connections Menu
The menu contains a table showing the terminals that are assigned a Connections
virtual port. The table includes the terminal name, serial number, IP address and
physical port to be connected to the selected virtual port. The
field defines the Status
current of the terminal:
- the terminal is on-line connected to the server and ready for Not Connected
virtual port connection.
- the terminal - virtual port connection is in progress. Connecting
- the terminal has been successfully interconnected with the virtual Connected
port.
