General Information and Specifications
2-14 3614RS, 4017RS
2.4 SPECIFICATIONS
2.4.1 Travel Speeds
2.4.2 Hydraulic Cylinder Performance
Note: Machine with no attachment or load, engine at full throttle, hydraulic oil above 54° C (130° F) minimum, engine at operating
temperature.
TRANSMISSION APPROXIMATE SPEED
First Gear 5 kph (3 mph)
Second Gear 12 kph (7 mph)
Third Gear 25 kph (15 mph)
FUNCTION
APPROXIMATE TIMES (seconds)
3614RS 4017RS
Boom Extend (Boom Level) 14.6 23.4
Boom Retract (Boom Level) 11.7 20.0
Boom Lift 15.5 21.0
Boom Lower 13.3 16.8
Quick Coupler Raise 3.1 3.1
Quick Coupler Lower 2.7 2.8
Frame Level - Full Right to Left 7.1 8.0
Frame Level - Full Left to Right 10.8 12.1
Outrigger - Both Down 6.9 7.0
Outrigger - Both Up 6.2 6.0
Outrigger - Single Down 4.4 4.5
Outrigger - Single Up 4.6 4.6
