9-43 3614RS, 4017RS
Electrical System
TRANSMISSION
FORWARD COIL –
OPEN CIRCUIT
33252 Continuously
Deactivate output J2-33
Transmission Forward Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Open circuit is detected on UGM J2-
33
Power cycled
TRANSMISSION
FORWARD COIL –
SHORT TO BATTERY
33253 Continuously
Deactivate output J2-33
Transmission Forward Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Short to battery is detected on UGM
J2-33
Power cycled
TRANSMISSION
FORWARD COIL –
SHORT TO GROUND
33254 Continuously
Deactivate output J2-33
Transmission Forward Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Short to ground is detected on UGM
J2-33
Power cycled
TRANSMISSION 1 ST
GEAR COIL – OPEN
CIRCUIT
33258 Continuously
Deactivate output J1-7 Transmission
1 st Gear Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Open circuit is detected on UGM J1-
7
Power cycled
TRANSMISSION 1 ST
GEAR COIL – SHORT
TO BATTERY
33259 Continuously
Deactivate output J1-7 Transmission
1 st Gear Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Short to battery is detected on UGM
J1-7
Power cycled
TRANSMISSION 1 ST
GEAR COIL – SHORT
TO GROUND
33260 Continuously
Deactivate output J1-7 Transmission
1
st
Gear Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Short to ground is detected on UGM
J1-7
Power cycled
TRANSMISSION 2 ND
GEAR COIL – OPEN
CIRCUIT
33264 Continuously
Deactivate output J1-20
Transmission 2 NDt Gear Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Open circuit is detected on UGM J1-
20
Power cycled
