Electrical System
9-42 3614RS, 4017RS
RIGHT STABILIZER UP
VALVE – SHORT TO
BATTERY
33232 Continuously
Stabilizers are prevented
Frame Level is prevented
Short to battery is detected on UGM
J2-3
Power cycled
RIGHT STABILIZER UP
VALVE – SHORT TO
GROUND
33233 5000Ms Stabilizers are prevented
Short to ground is detected on UGM
J2-3
Power cycled
FRAME LEVEL LEFT
VALVE – OPEN
CIRCUIT
33234 5000Ms Frame Level Left is prevented
Open circuit is detected on UGM J2-
7
Power cycled
FRAME LEVEL LEFT
VALVE – SHORT TO
BATTERY
33235 Continuously
Stabilizers are prevented
Frame Level is prevented
Short to battery is detected on UGM
J2-7
Power cycled
FRAME LEVEL LEFT
VALVE – SHORT TO
GROUND
33236 5000Ms Frame Level Left is prevented
Short to ground is detected on UGM
J2-7
Power cycled
FRAME LEVEL RIGHT
VALVE – OPEN
CIRCUIT
33237 5000Ms Frame Level Right is prevented
Open circuit is detected on UGM J2-
5
Power cycled
FRAME LEVEL RIGHT
VALVE – SHORT TO
BATTERY
33238 Continuously
Stabilizers are prevented
Frame Level is prevented
Short to battery is detected on UGM
J2-5
Power cycled
FRAME LEVEL RIGHT
VALVE – SHORT TO
GROUND
33239 5000Ms Frame Level Right is prevented
Short to ground is detected on UGM
J2-5
Power cycled
TRANSMISSION
REVERSE COIL – OPEN
CIRCUIT
33246 Continuously
Deactivate output J2-32
Transmission Reverse Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Open circuit is detected on UGM J2-
32
Power cycled
TRANSMISSION
REVERSE COIL –
SHORT TO BATTERY
33247 Continuously
Deactivate output J2-32
Transmission Reverse Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Short to battery is detected on UGM
J2-32
Power cycled
TRANSMISSION
REVERSE COIL –
SHORT TO GROUND
33248 Continuously
Deactivate output J2-32
Transmission Reverse Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display at 1.25Hz.
Direction Selection shall be Neutral
when Calibration’s TRANS SERVICE is
NO
Short to ground is detected on UGM
J2-32
Power cycled
