79
BOOM LIFT MODELS X23J
JLG
X23JR0620113
STARTING THE DIESEL ENGINE FROM THE KEY:
Take the key into the HEAT position and hold it in position for 10‑15 seconds. Then
release and start the engine.
STARTING THE DIESEL ENGINE FROM REMOTE CONTROL : press and release button
10. Pressing the button determines pre‑heating equal to 10 seconds. In case of advanced
start‑up, the pre‑heating ends on start‑up.
THE ENGINE MUST ALWAYS BE STARTED UP WITH ALL BUTTONS AND CONTROL
JOYSTICKS IN THE NEUTRAL POSITION.
Always check that there are no foreign elements (e.g. branches) that accidentally activate a
control. The platform could move unexpectedly independently from the will of the operator
and cause serious damage/injury to objects and/or persons.
Check that all manual controls of the proportional coils are at rest.
6.4.3 S TARTING THE ELECTRIC ENGINE
‑ Before starting the engine it is indispensable to know and be clear about all procedures
described in the machine USE AND MAINTENANCE
MANUAL and to know the meaning of the safety adhe‑
sive stickers.
‑ It is necessary to examine the summary table regarding
the Safety Standards for the operator and have applied
all provisions.
‑ Power the machine using an electric cable through the
coupling positioned below in proximity of the electric
engine. Arm the switch positioned in the electric control
board in proximity of the engine (see photo).
