127
BOOM LIFT MODELS X23J
JLG
X23JR0620113
Heavy parts must e lifted using a lifting device with suitable capacity.
• It is prohibited to carry out any maintenance operations with the working arm not com‑
pletely lowered and/or the machine stabilised.
• If interventions are being carried out, apply a visible sign on the ignition board stating
"DANGER. Do not move the machine, checks in progress".
7.6 O PERATING THE MACHINE FROM THE SECOND CONTROL POSITION ON THE GROUND USING THE
OPTIONAL SECOND REMOTE CONTROL DURING MAINTENANCE
This type of operation is only allowed in the event of maintenance on the machine by expert
personnel.
For the controls from the ground position with the optional second remote control, see the
corresponding paragraph.
‑ Stop the machine, key in the OFF position.
‑ Take the key to enable emergency descent from the group of keys inside the electrical
components compartment.
‑ Insert the key in the control panel on the emergency control position and select the
remote control on the ground.
‑ Connect the optional second remote control following the procedure specified in the cor‑
responding paragraph (make sure the contacts of the connectors on the remote control
and the machine are completely dry).
‑ Start the machine, key in the ON position.
‑ Check that the icons are correctly shown on the display on the remote control in the
ground position.
‑ Move the aerial part of the machine using the remote control from the ground, following
the instructions given in the paragraphs regarding the operation of the machine. If the
load in the basket exceeds 50 kg, to use the remote control from the ground hold button
8 and then activate the required movement.
IMPORTANTE IMPORTANT
