9 R EMOTE CONTROL SERVICE MENU
A SERVICE button is present on the remote control (ref. button), which allows to view the
status of the machine parameters and is an aid in the safety checks of the machine, envisio‑
ned in this manual.
By pressing button 6 a numerical menu is accessed, which is controlled by the remote control
keys used with numerical meaning. The meaning of these menus is only understood after
careful reading of this manual. If in doubt, contact the JLG after‑sales service.
1 INPUT
2 LANGUAGE
3 ERRORS
4 RAMPS
5 CURRENT
6 OP. HOURS
7 SETTINGS
8 JOYSTICK
9 EXIT
I M
ENUS 2; 4; 5; CANNOT BE ACCESSED
9.1 M ENU ' INPUT
The signals that arrive at the board from the various sensors mounted on the machine and
from the remote control commands are displayed. The status of the input and the following
selection to scroll the menu appears for each screen:
1 PREC' access the previous input
2 SUCC' access the successive input
9 ESCI ' escape from the INPUT menu
BOOM LIFT MODELS X23J
JLG
168 X23JR0620113
ST TERR 1A
Both ON indicate the stabilizer 1 rests on the ground. ST TERR 1B
ST TERR 2A
Both ON indicate the stabilizer 2 rests on the ground. ST TERR 2B
ST TERR 3A
Both ON indicate the stabilizer 3 rests on the ground. ST TERR 3B
ST TERR 4A
Both ON indicate the stabilizer 4 rests on the ground. ST TERR 4B
ST APERT1A
Both ON indicate the stabilizer 1 is completely open, TOTAL AREA. ST APERT1B
ST APERT2A
Both ON indicate the stabilizer 2 is completely open, TOTAL AREA ST APERT2B
ST APERT3A
Both ON indicate the stabilizer 3 is completely open, TOTAL AREA ST APERT3B
ST APERT4A
Both ON indicate the stabilizer 4 is completely open, TOTAL AREA ST APERT4B
