63
4.2 F
OOTSWITCH
Inside of the basket is fitted a footswitch device that must be pushed to allow the movement
of the machine from the basket. If you try to move the machine without the footswitch
pushed the movement will be prohibited and a message on the display will appear infor‑
ming that it is necessary push the pedal to work. If you have not made moves to 7 seconds
after pressing the pedal this must be release and pressed again to resume work.
4.3 C ONTROL POSITIONS
Refer to paragraph 2.1.1 Control position.
BOOM LIFT MODELS X23J
