BOOM LIFT MODELS X23J
JLG
60 X23JR0620113
BUTTON 2:
Allows to enter in “manual movements menu” of individual stabilizers.
BUTTONS 3‑9:
Allow to widen and narrow the tracked undercarriage.
BUTTON 4:
Allows enabling of the emergency descent from basket.
Confirmation of enabling is displayed on the screen in position 8.
BUTTON 5:
Allows to select the traversing speed and motor revs.
There are three possible speeds:
• S
LOW : engine at 1500 rpm for functioning of the aerial part, 2200 rpm for functioning of
the track part. Minimum speed possible for trailers.
• N
ORMAL
: engine revs variable depending on the movement selected. Traversing engines
