59
BOOM LIFT MODELS X23J
JLG
X23JR0620113
4.1.3 B
UTTONS
The buttons have a double function: they can be used to select machine functions or as
numerical keys in the service sub‑menus.
They are in fact characterised by an icon that represents the meaning and by a number that
characterises them in use as a numerical keyboard.
An emergency STOP is also present which, if pressed stops the engine and brings the machi‑
ne to a standstill. The non‑released position of the emergency STOP is represented on the
display in position 7.
To allow the machine to become operational again, the button must be turned.
For the single functions use refer to paragraph 6 Machine use.
BUTTON 1:
It enables to carry out the auto‑destabilization of the machine.
6
FORWARD JIB OPENING
REVERSE JIB CLOSURE
7
FORWARD ANTI‑CLOCKWISE ROTATION
REVERSE CLOCKWISE ROTATION
8
FORWARD RIGHT TRAVEL FORWARD
REVERSE RIGHT TRAVEL REVERSE
9
RIGHT BASKET LEVELLING CLOSURE
LEFT BASKET LEVELLING OPENING
