53
BOOM LIFT MODELS X23J
JLG
X23JR0620113
POSITION 1:
Position no. 1 relates the icon of reduced area in case the machine is stabilized in this confi‑
guration.
POSITION 2:
Position no. 2 displays the max weight based on the working mode: 120kg / 200kg
POSITION 3:
Position 3 displays the selected engine and the engine status.
Petrol/diesel engine Electric engine
An X present on the icon indicates that the engine is off; no X indicates that the engine is on.
POSITION 4:
Position 4 displays the selected speed or the reduced speed for the Lithium:
SLOW NORMAL FAST REDUCED
