Electrical System
9-52
G5-18A, 2505H, 25.5
1216
523914
5
Glow plug control release line; short circuit error
1217
523914
11
Glow plug control; internal error
1219
524018
14
DPF wasn't regenerated, power reduction phase 1 (manual
regeneration request)
1220
524022
14
DPF wasn't regenerated, power reduction phase 2 (manual
regeneration request)
1221
524023
14
DPF wasn't regenerated, warning condition (manual regeneration mode)
1222
190
14
Camshaft- and Crankshaft speed sensor signal not available on CAN
1223
51
5
Actuator EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); open load
1224
51
6
Actuator EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); over current
1225
51
12
Actuator EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); over temperature
1226
51
3
EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); short circuit to battery (A02)
1227
51
3
EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); short circuit to battery (A67)
1228
51
4
EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); short circuit to ground (A02)
1229
51
4
EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); short circuit to ground (A67)
1230
51
6
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); Overload by short-
circuit
1231
51
11
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); Power stage over
temperature due to high current
1232
51
4
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); Voltage
below threshold
1239
523984
3
UB6; Short circuit to battery error of actuator relay 7
1240
523985
3
UB7; Short circuit to battery error of actuator relay £
1243
523988
5
Charging lamp; open load
1244
523988
12
Charging lamp; over temperature
1245
523988
3
Charging lamp; short circuit to battery
1246
523988
4
Charging lamp; short circuit to ground
1247
524019
11
Air Pump; air lines blocked
1248
523910
9
Air Pump; CAN communication lost
1249
523910
7
Air pump; CAN communication interrupted no purge function available
1250
523910
12
Air Pump; internal error
1251
523910
0
Air Pump; power stage over temperature
1252
523910
0
Air Pump; operating voltage error
1253
523911
7
Burner dosing valve (DV2); blocked closed
1254
524014
1
Air pressure glow plug flush line; below limit
1255
524013
7
Burner operation is interrupted too often
1256
523915
7
HCI dosing valve (DV1); blocked closed
1257
523915
7
HCI dosing valve (DV1); blocked open
1258
524016
11
HFM sensor; electrical fault
1259
524016
2
Amount of air is not plausible to pump speed
1260
524016
2
Calculated amount of air is not plausible to HFM reading
1261
523910
6
Air Pump; over current
1262
523922
7
Burner Shut Off Valve; blocked closed
1263
524021
11
Burner fuel line pipe leak behind Shut Off Valve
1264
523922
7
Burner Shut Off Valve; blocked open
Fault
Codes
SPN
Codes
FMI
Codes
Deutz Description
