Electrical System
9-42
G5-18A, 2505H, 25.5
292
523777
9
Passive Time out Error of CAN-Receive-Frame TSC1TE; Set point
293
523778
9
Active Time out Error of CAN-Receive-Frame TSC1TR
294
523779
9
Passive Time out Error of CAN-Receive-Frame TSC1TR
299
523788
12
Time out Error of CAN-Transmit-Frame TrbCH; Status Wastegate
300
523605
9
Time out Error of CAN-Receive-Frame TSC1AE; Traction Control
301
523606
9
Time out Error of CAN-Receive-Frame TSC1AR; Retarder
305
898
9
Time out Error of CAN-Receive-Frame TSC1TE; Set point
306
520
9
Time out Error of CAN-Receive-Frame TSC1TR; Set point
322
523867
12
Time out Error of CAN-Transmit-Frame UAA1 on CAN 2; Burner Air
Pump Control
360
523982
0
Powerstage diagnosis disabled; high battery voltage
361
523982
1
Powerstage diagnosis disabled; low battery voltage
376
630
12
Access error EEPROM memory (delete)
377
630
12
Access error EEPROM memory (read)
378
630
12
Access error EEPROM memory (write)
381
411
4
Physical range check low for EGR differential pressure
383
2791
5
Actuator EGR Valve; open load
384
2791
12
Actuator EGR Valve; powerstage over temperature
385
2791
3
Actuator EGR Valve; short circuit to battery
386
2791
4
Actuator EGR Valve; short circuit to ground
387
523612
12
Internal software error ECU; injection cut off
388
190
0
Overspeed detection in component engine protection
389
190
0
Engine speed above warning threshold (FOC-Level 1)
390
190
11
Engine speed above warning threshold (FOC-Level 2)
391
190
14
Engine speed above warning threshold (Overrun Mode)
412
108
3
Sensor error ambient air pressure; signal range check high
413
108
4
Sensor error ambient air pressure; signal range check low
417
171
3
Sensor error environment temperature; signal range check high
418
171
4
Sensor error environment temperature; signal range check low
419
190
8
Sensor camshaft speed; disturbed signal
420
190
12
Sensor camshaft speed; no signal
421
190
2
Offset angle between crank- and camshaft sensor is too large
422
190
8
Sensor crankshaft speed; disturbed signal
423
190
12
Sensor crankshaft speed; no signal
424
703
5
Engine running lamp; open load
425
703
12
Engine running lamp; powerstage over temperature
426
703
3
Engine running lamp; short circuit to battery
427
703
4
Engine running lamp; short circuit to ground
450
975
5
Digital fan control; open load
451
975
12
Digital fan control; powerstage over temperature
452
975
3
Digital fan control; short circuit to battery
453
975
4
Digital fan control; short circuit to ground
455
975
5
Fan actuator (PWM output); open load
456
975
12
Fan actuator (PWM output); powerstage over temperature
Fault
Codes
SPN
Codes
FMI
Codes
Deutz Description
