JLG G5-18A Service Manual User Manual
Page 169

9-49
G5-18A, 2505H, 25.5
Electrical System
995
105
4
Sensor error charged air temperature; signal range check low
996
105
0
High charged air cooler temperature; warning threshold exceeded
997
105
0
High charged air cooler temperature; shut off threshold exceeded
1007
412
3
Sensor error EGR cooler downstream temperature; signal range check high
1008
412
4
Sensor error EGR cooler downstream temperature; signal range check low
1009
412
2
Sensor exhaust gas temperature Venturi unit (EGR); plausibility error
1011
523960
0
Physical range check high for EGR cooler downstream temperature
1012
523960
1
Physical range check low for EGR cooler downstream temperature
1013
523960
11
Sensor exhaust gas temperature Venturi unit (EGR); plausibility error
1014
51
6
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); signal range check
high
1015
51
5
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); signal range check
low
1016
51
7
Actuator position for EGR-Valve (2.9,3.6) or Throttle-Valve (6.1,7.8)
not plausible
1017
51
5
Actuator EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); open load
1018
51
12
Actuator EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); power stage
over temperature
1019
51
3
EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); short circuit to battery
1020
51
4
EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); short circuit to ground
1021
51
12
Mechanical actuator defect EGR-Valve (2.9,3.6) or Throttle-Valve (6.1,7.8)
1022
51
6
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); signal range check
high
1023
51
5
Actuator error EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); signal range check
low
1024
51
3
Position sensor error of actuator EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8);
signal range check high
1025
51
4
Position sensor error actuator EGR-Valve (2.9;3.6) or Throttle-Valve (6.1,7.8); signal
range check low
1026
4769
2
Sensor exhaust gas temperature downstream (DOC); plausibility error
1029
4766
0
Physical range check high for exhaust gas temperature downstream (DOC)
1032
4766
1
Physical range check low for exhaust gas temperature downstream (DOC)
1034
4769
3
Sensor error exhaust gas temperature downstream (DOC); signal range check high
1035
4769
4
Sensor error exhaust gas temperature downstream (DOC); signal range check low
1036
4768
2
Sensor exhaust gas temperature upstream (DOC); plausibility error
1039
4765
0
Physical range check high for exhaust gas temperature upstream (DOC)
1042
4765
1
Physical range check low for exhaust gas temperature upstream (DOC]
1044
4768
3
Sensor error exhaust gas temperature upstream (DOC); signal range
check high
1045
4768
4
Sensor error exhaust gas temperature upstream (DOC); signal range
check low
1047
3248
4
Sensor error particle filter downstream temperature; signal range check low
1066
1180
11
Sensor exhaust gas temperature upstream turbine; plausibility error
1067
1180
3
Sensor error exhaust gas temperature upstream turbine; signal range
check high
Fault
Codes
SPN
Codes
FMI
Codes
Deutz Description
