8-29 G5-18A, 2505H, 25.5
Hydraulic System
8.12.8 Hydraulic Cylinder Torque
Specifications
a. Lift Lower Cylinder
b. Extend/Retract Cylinder
c. Tilt Cylinder
d.
Compensating Cylinder
Use Loctite ® 262 TM on all Piston Applications
Use Loctite ® 242 TM on all Set Screws
Head Piston CB Valve Valve Screw FC Valve Set Screw
300-400 lb-ft
(406-542 Nm)
1800-2000 lb-ft
(2440-2712 Nm)
45-50 lb-ft
(61-67,7 Nm)
20-25 lb-ft
(27-33,8 Nm)
30-35 lb-ft
(40,6-47,5 Nm)
11 lb-ft (15 Nm)
Head Piston Valve Valve Screw Set Screw
200-250 lb-ft
(271-339 Nm)
200-240 lb-ft
(271-325 Nm)
44 lb-ft
(60 Nm)
10-12 lb-ft
(14-16 Nm)
60-69 lb-ft
(81-94 Nm)
Head Piston Valve Valve Screw Set Screw
300-400 lb-ft
(406-542 Nm)
1400-1500 lb-ft
(1898-2034 Nm)
44 lb-ft
(60 Nm)
10-12 lb-ft
(14-16 Nm)
11 lb-ft (15 Nm)
Head Piston Valve Valve Screw Set Screw
300-400 lb-ft
(406-542 Nm)
1400-1500 lb-ft
(1898-2034 Nm)
44 lb-ft
(60 Nm)
10-12 lb-ft
(14-16 Nm)
11 lb-ft (15 Nm)
