9-43
G5-18A, 2505H, 25.5
Electrical System
457
975
3
Fan actuator (PWM output); short circuit to battery
458
975
4
Fan actuator (PWM output); short circuit to ground
460
1639
0
Sensor error fan speed; signal range check high
461
1639
1
Sensor error fan speed; signal range check low
462
523602
0
High fan speed; warning threshold exceeded
463
523602
0
High fan speed; shut off threshold exceeded
464
97
3
Sensor error water in fuel; signal range check high
465
97
4
Sensor error water in fuel; signal range check low
472
94
3
Sensor error low fuel pressure; signal range check high
473
94
4
Sensor error low fuel pressure; signal range check low
474
94
1
Low fuel pressure; warning threshold exceeded
475
94
1
Low fuel pressure; shut off threshold exceeded
481
174
0
High low fuel temperature; warning threshold exceeded
482
174
0
High Low fuel temperature; shut off threshold exceeded
488
523619
2
Physical range check high for exhaust gas temperature up stream (SCR-CAT)
500
523915
0
HCI dosing valve (DV1); over current at the end of the injection phase
501
523915
12
HCI dosing valve (DV1); powerstage over temperature
502
523915
3
HCI dosing valve (DV1); short circuit to battery
503
523915
3
HCI dosing valve (DV1); short circuit to battery high side
504
523915
4
HCI dosing valve (DV1); short circuit to ground
505
523915
11
HCI dosing valve (DV1); short circuit high side powerstage
506
523916
2
Sensor HCI dosing valve (DV1) downstream pressure; plausibility error
508
523916
0
Physical range check high for HCI dosing valve (DV1) downstream pressure; shut
off regeneration
511
523916
1
Physical range check low for HCI dosing valve (DV1) downstream pressure; shut off
regeneration
514
523916
3
Sensor error HCI dosing valve (DV1) downstream pressure; signal range check high
515
523916
4
Sensor error HCI dosing valve (DV1) downstream pressure; signal range check low
516
523917
2
Sensor DV1 & DV2 upstream pressure; plausibility error
518
523917
0
Physical range check high for DV1 & DV2 upstream pressure;
shut off regeneration
521
523917
1
Physical range check low for DV1 & DV2 upstream pressure;
shut off regeneration
524
523917
3
Sensor error DV1 & DV2 upstream pressure; signal range check high
525
523917
4
Sensor error DV1 & DV2 upstream pressure; signal range check low
526
523918
2
Sensor DV1 & DV2 upstream temperature; plausibility error
528
523918
0
Physical range check high for DV1 & DV2 upstream temperature;
shut off regeneration
531
523918
1
Physical range check low for DV1 & DV2 upstream temperature; shut off
regeneration
534
523918
3
Sensor error DV1 & DV2 upstream temperature; signal range check high
535
523918
4
Sensor error DV1 & DV2 upstream temperature; signal range check low
543
676
11
Cold start aid relay error.
544
676
11
Cold start aid relay open load
545
729
5
Cold start aid relay open load
Fault
Codes
SPN
Codes
FMI
Codes
Deutz Description
