SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
3121619 – JLG Lift – 7-57
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1
2 BLK 248-2 INJECTOR 3 1.5 mm² FLRYW EIC (61)
3 BLK 248-3 INJECTOR 2 1.5 mm² FLRYW EIC (41)
4 BLK 248-4MPROP ACTUATOR 1.5 mm² FLRYW EIC (19)
5 BLK 248-5MPROP ACTUATOR 1.5 mm² FLRYW EIC (20)
6
7 BLK 248-7 RAIL PRESSURE FUEL 0.75 mm² FLRYW EIC (32)
8
9
10
11
12
13
14
15
16 BLK 248-16 INJECTOR 1 1.5 mm² FLRYW EIC (35)
17
18 BLK 248-18 INJECTOR 4 1.5 mm² FLRYW EIC (37)
19 BLK 248-19EHXAUST GAS RECIRCULATION 1.5 mm² FLRYW EIC (47)
20 BLK 248-20EHXAUST GAS RECIRCULATION 1.5 mm² FLRYW EIC (48)
21
22
23 BLK 248-23 GLOW SENSE 0.75 mm² FLRYW FC1003 (1)
24 BLK 248-24 BOOST PRESSURE / TEMP 0.75 mm² FLRYW EIC (22)
25 BLK 248-25 RAIL PRESSURE FUEL 0.75 mm² FLRYW EIC (31)
26 BLK 248-26 RAIL PRESSURE FUEL 0.75 mm² FLRYW EIC (25)
27 BLK 248-27 BOOST PRESSURE / TEMP 0.75 mm² FLRYW EIC (29)
28 BLK 248-28COOLING TEMPERATURE 0.75 mm² FLRYW EIC (24)
29 BLK 248-29 OIL PRESSURE 0.75 mm² FLRYW EIC (27)
30
31
32 BLK 248-32 INJECTOR 3 1.5 mm² FLRYW EIC (38)
33 BLK 248-33 INJECTOR 1 1.5 mm² FLRYW EIC (62)
34
35 BLK 248-35GLOW RELAY CONTROL GND 0.75 mm² FLRYW RL931-85 (1)
36
37 BLK 248-37ENGINE SPEED CAMSHAFT 0.75 mm² FLRYW EIC (14)
38 SHLD 248-38ENGINE SPEED CRANKSHAFT 0.75 mm² SHLD EIC (1)
39 BLK 248-39ENGINE SPEED CRANKSHAFT 0.75 mm² FLRYW EIC (15)
40 BLK 248-40 AIR INLET TEMP 0.75 mm² FLRYW EIC (28)
41
42
43 BLK 248-43 OIL PRESSURE 0.75 mm² FLRYW EIC (23)
44 BLK 248-44 OIL PRESSURE 0.75 mm² FLRYW EIC (26)
45
46 BLK 248-46 INJECTOR 2 1.5 mm² FLRYW EIC (40)
47
48 BLK 248-48 INJECTOR 4 1.5 mm² FLRYW EIC (42)
49
50
51
52 BLK 248-52ENGINE SPEED CAMSHAFT 0.75 mm² FLRYW EIC (13)
53 SHLD 248-53ENGINE SPEED CAMSHAFT 0.75 mm² SHLD EIC (9)
54 BLK 248-54ENGINE SPEED CRANKSHAFT 0.75 mm² FLRYW EIC (21)
55
56
57
58
59
60
Figure 7-62. T4i Engine Harness - Sheet 4 of 4
