SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
7-24 – JLG Lift – 3121619
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 5V 18 AWG GXL CO128-J3 (2)
2 WHT 5V 18 AWG GXL CO128-J3 (1)
3
4 RED BANG 1 18 AWG CABLE SN130 (5)
5 BLU BANG 2 18 AWG CABLE SN130 (3)
6 BLK BANG 1 18 AWG CABLE SN130 (4)
7 RED B LNGTH 18 AWG CABLE X404B (1)
8 BLU B LNGTH 18 AWG CABLE X404B (2)
9 BLK B LNGTH 18 AWG CABLE X404B (3)
10 RED BANG 2 18 AWG CABLE SN130 (2)
11 BLU BANG 1 18 AWG CABLE SN130 (6)
12 BLK BANG 2 18 AWG CABLE SN130 (1)
CO128-J1
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 YEL IGN JUMP 18 AWG GXL CO128-J1 (11)
2 BLK GND JUMP 18 AWG GXL CO128-J1 (12)
3
4 BLK 0-22 14 AWG GXL X411 (1)
5 YEL 2-10 14 AWG GXL X411 (2)
6 YEL CAN HIGH 18 AWG GXL MS148-1 (A)
7 GRN CAN LOW 18 AWG GXL MS148-1 (B)
8
9
10
11 YEL IGN JUMP 18 AWG GXL CO128-J1 (1)
12 BLK GND JUMP 18 AWG GXL CO128-J1 (2)
SN130
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 BLK BANG 2 18 AWG CABLE CO128-J3 (12)
2 RED BANG 2 18 AWG CABLE CO128-J3 (10)
3 BLU BANG 2 18 AWG CABLE CO128-J3 (5)
4 BLK BANG 1 18 AWG CABLE CO128-J3 (6)
5 RED BANG 1 18 AWG CABLE CO128-J3 (4)
6 BLU BANG 1 18 AWG CABLE CO128-J3 (11)
CO128-J5
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 WHT 7-4 LDRV PFWD 18 AWG GXL X222B (6)
2 WHT 7-3 LDRV PREV 18 AWG GXL X222B (5)
3
4
5
6
7
8
9 YEL 1-10 18 AWG GXL X406A (1)
10
11
12 BLK 0-15 18 AWG GXL X222B (3)
CO128-J2
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 YEL 1-11 18 AWG GXL X406A (5)
2 BLK 0-56 18 AWG GXL X406A (7)
3 BLK 0-55 18 AWG GXL X406A (3)
4
5
6
7
8
WHT 49-60 GRVTY SEN1 18 AWG GXL X406A (2)
9 WHT 49-61 GRVTY SEN2 18 AWG GXL X406A (6)
10
11 WHT 7-1 RDRV PFWD 18 AWG GXL X222B (1)
12 WHT 7-2 RDRV PREV 18 AWG GXL X222B (2)
X406A
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 YEL 1-10 18 AWG GXL CO128-J5 (9)
2 WHT 49-60 GRVTY SEN1 18 AWG GXL CO128-J2 (8)
3 BLK 0-55 18 AWG GXL CO128-J2 (3)
4
5 YEL 1-11 18 AWG GXL CO128-J2 (1)
6 WHT 49-61 GRVTY SEN2 18 AWG GXL CO128-J2 (9)
7 BLK 0-56 18 AWG GXL CO128-J2 (2)
8
X404B
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 RED B LNGTH 18 AWG CABLE CO128-J3 (7)
2 BLU B LNGTH 18 AWG CABLE CO128-J3 (8)
3 BLK B LNGTH 18 AWG CABLE CO128-J3 (9)
4
5 RED BRKN CBL PROX 18 AWG CABLE X411 (5)
6 BLU BRKN CBL PROX 18 AWG CABLE X411 (3)
7 BLK BRKN CBL PROX 18 AWG CABLE X411 (4)
8 SHIELD BRKN CBL PROX 18 AWG SHLD X411 (6)
X222B
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 7-1 RDRV PFWD 18 AWG GXL CO128-J2 (11)
2 WHT 7-2 RDRV PREV 18 AWG GXL CO128-J2 (12)
3 BLK 0-15 18 AWG GXL CO128-J5 (12)
4
5
WHT 7-3 LDRV PREV 18 AWG GXL CO128-J5 (2)
6 WHT 7-4 LDRV PFWD 18 AWG GXL CO128-J5 (1)
X421
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 SHIELD B LNGTH 18 AWG SHLD X404B (NC)
X411
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 BLK 0-22 14 AWG GXL CO128-J1 (4)
2 YEL 2-10 14 AWG GXL CO128-J1 (5)
3 BLU BRKN CBL PROX 18 AWG CABLE X404B (6)
4 BLK BRKN CBL PROX 18 AWG CABLE X404B (7)
5 RED BRKN CBL PROX 18 AWG CABLE X404B (5)
6 SHIELD BRKN CBL PROX 18 AWG SHLD X404B (8)
MS148-1
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
A YEL CAN HIGH 18 AWG GXL CO128-J1 (6)
B GRN CAN LOW 18 AWG GXL CO128-J1 (7)
C
X413
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 SHIELD CABLE SHIELD 18 AWG SHLD SN130 (NC)
1 SHIELD CABLE SHIELD 18 AWG SHLD SN130 (NC2)
Figure 7-29. BLAM Module Wiring Harness - Sheet 2 of 2
