SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
3121619 – JLG Lift – 7-37
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 RED 1-7-2 WK LT PWR 16 AWG GXL IP379 (2)
2 RED 1-7-1 WK LT PWR 16 AWG GXL IP379 (2)
3 WHT 50-3 JIB DUM P 16 AWG GXL X159B (5)
4 WHT 50-2 PLT F M DUM P 16 AWG GXL X159B (4)
X81
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 SHLD CAN SHLD 20 AWG J1939 CABLE M S82 (5)
2 GRN CAN LO 20 AWG J1939 CABLE M S82 (9)
3 YEL CAN HI 20 AWG J1939 CABLE M S82 (11)
4 YEL 2-4 18 AWG GXL S89 (1)
5 RED 1-4-3 18 AWG GXL X327B (3)
6 YEL 2-15 18 AWG GXL CO02-J7 (15)
7 WHT 25-5 PLVL DN O/R 18 AWG GXL X159B (3)
8
9 WHT 25-6 PLVL UP O/R 18 AWG GXL X159B (2)
10 YEL 2-25 12 AWG GXL RL235-Y (1)
11 YEL 2-5 18 AWG GXL CO02-J7 (14)
12 YEL 2-26 12 AWG GXL RL235-Y (1)
13 WHT 27-6 J-UP O/R 18 AWG GXL CO02-J1 (3)
14
15 WHT 27-3 JIB DN O/R 18 AWG GXL X159B (1)
16 BLK 0-40 12 AWG GXL X378 (1)
17
18 BLK 0-41 12 AWG GXL X377 (1)
19
SN123
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 RED B LNT H CBL 18 AWG CABLE CO02-J7 (35)
2 BLK B LNT H CBL 18 AWG CABLE CO02-J7 (11)
3
4 WHT B LNT H CBL 18 AWG CABLE CO02-J7 (29)
S89
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 YEL 2-4 18 AWG GXL X81 (4)
1 YEL 2-4-2 18 AWG GXL IP90 (2)
2 YEL 2-4-3 18 AWG GXL CO02-J7 (2)
2 YEL 2-4-4 18 AWG GXL CO02-J7 (1)
LB417
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 YEL 2-17 18 AWG GXL X353 (1)
2 BLK 0-16 18 AWG GXL X237 (1)
X420
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 BLK 0-50-1 16 AWG GXL S456 (2)
X84
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 BLK 0-19-2 18 AWG GXL S239 (2)
2 RED 1-15 18 AWG GXL IP414 (1)
3 YEL CAN HI 20 AWG J1939 CABLE M S83 (11)
4 GRN CAN LO 20 AWG J1939 CABLE M S83 (4)
5 SHLD CAN SHLD 20 AWG J1939 CABLE M S83 (7)
6
7
8 YEL 2-11-1 18 AWG GXL IP85 (1)
9
MS148-3
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
A YEL CAN HI 20 AWG J1939 CABLE M S82 (12)
B GRN CAN LO 20 AWG J1939 CABLE M S82 (10)
C SHLD CAN SHLD 20 AWG J1939 CABLE M S82 (7)
MS148-2
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
A YEL CAN HI 18 AWG J1939 CABLE X147A (1)
B GRN CAN LO 18 AWG J1939 CABLE X147A (2)
C SHLD CAN SHLD 18 AWG J1939 CABLE X147A (3)
X440B
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 WHT 55-30 LF T ENABLE 18 AWG GXL CO02-J1 (1)
2 WHT 49-77 P C PWR 20 AWG GXL CO02-J7 (26)
3 WHT 49-76 P C GND 20 AWG GXL CO02-J7 (10)
4 WHT 49-75 PRS CHK 20 AWG GXL CO02-J7 (7)
5 WHT 49-73 L P PWR 20 AWG GXL CO02-J7 (16)
6 WHT 49-74 L P GND 20 AWG GXL CO02-J7 (9)
7 WHT 49-72 LIF T PRS 20 AWG GXL CO02-J7 (4)
8 BLK 0-50-2 16 AWG GXL S456 (1)
S456
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 BLK 0-50 16 AWG GXL X419 (1)
1 BLK 0-50-2 16 AWG GXL X440B (8)
2 BLK 0-50-1 16 AWG GXL X420 (1)
Figure 7-42. Turntable Wiring Harness - Sheet 6 of 9
