SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
7-52 – JLG Lift – 3121619
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 50-3 JIB DUM P 16 AWG GXL X159A (5)
2 WHT 55-31 CHS ENABLE 18 AWG GXL HV314 (1)
3 WHT 50-2 PLT F RM DUM P 16 AWG GXL X159A (4)
4 WHT 13-4 M T ELE IN 18 AWG GXL HV109 (1)
5 WHT 25-6 PLVL UP O/R 18 AWG GXL X159A (2)
6 BLK 0-11 16 AWG GXL S156 (1)
7 WHT 25-5 PLVL DN O/R 18 AWG GXL X159A (3)
8
9 WHT 55-12 T ELE F CNT RL 18 AWG GXL HV108 (1)
10 WHT 55-11 LF T PLT 18 AWG GXL HV107 (1)
11 WHT 3-2 M LIF T UP 18 AWG GXL HV106 (1)
12 WHT 55-10 LF T DN AUX 18 AWG GXL HV105 (1)
13 WHT 50-1 M AIN DUM P 18 AWG GXL HV104 (1)
14 BLK 0-10 16 AWG GXL S154 (1)
15 WHT 22-2 SWG LF T 18 AWG GXL HV100 (1)
16 WHT 13-3 M T ELE OUT 18 AWG GXL HV103 (1)
17 BLK 0-36 18 AWG GXL HV314 (2)
18 BLK 0-30 18 AWG GXL S153 (1)
19 WHT 55-9 LF T F CNT RL 18 AWG GXL HV102 (1)
20
21
22 WHT 3-1 M LIF T DN 18 AWG GXL HV101 (1)
23
24
25 WHT 47-10 F UL SEN 18 AWG GXL SN114 (1)
26 WHT 52-7 H&T LT SIG 18 AWG GXL X158 (1)
27 WHT 52-6 M OT ALRM 18 AWG GXL AH318 (B)
28
29
30 BLK 0-6 16 AWG GXL S155 (1)
31 WHT 27-3 JIB DN O/R 18 AWG GXL X159A (1)
32 WHT 22-1 SWG RHT 18 AWG GXL HV99 (1)
33 WHT 55-33 WARM UP 18 AWG GXL HV316 (1)
34
35 WHT 55-32 SWG F.C. 18 AWG GXL HV348 (1)
CO 02-J3
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 60-1 LF CNT RL RT N 18 AWG GXL HV102 (2)
2 WHT 60-2 T F CNT RL RT N 18 AWG GXL HV108 (2)
3
4 WHT 60-3 SWG RT N 18 AWG GXL HV348 (2)
5 WHT 60-6 WARM UP RT N 18 AWG GXL HV316 (2)
6
7 WHT 52-8 ALRM PWR 18 AWG GXL AH318 (A)
8
9 WHT 47-6 ALT EXC 18 AWG GXL X159A (12)
10
11
12
13
14 WHT 60-7 LENABLE RT N 18 AWG GXL HV315 (2)
HV315
LIFT ENABLE
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 WHT 55-30 LF T ENABLE 18 AWG GXL X440A (1)
2 WHT 60-7 LENABLE RT N 18 AWG GXL CO02-J3 (14)
SN114
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 47-10 F UL SEN 18 AWG GXL CO02-J2 (25)
2 BLK 0-14-3 18 AWG GXL S157 (2)
S153
CONNECT OR PART NUM BER: SPLICE
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
T ERM INAL
P/N
T O
1 BLK 0-30 18 AWG GXL N/A CO02-J2 (18)
2 BLK 0-30-1 18 AWG GXL N/A HV100 (2)
2 BLK 0-30-2 18 AWG GXL N/A HV99 (2)
S154
CONNECT OR PART NUM BER: SPLICE
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET
T ERM INAL
P/N T O
1 BLK 0-10 16 AWG GXL N/A CO02-J2 (14)
2 BLK 0-10-1 18 AWG GXL N/A HV107 (2)
2 BLK 0-10-2 18 AWG GXL N/A HV104 (2)
S155
CONNECT OR PART NUM BER: SPLICE
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET
T ERM INAL
P/N T O
1 BLK 0-6 16 AWG GXL N/A CO02-J2 (30)
2 BLK 0-6-1 18 AWG GXL N/A HV106 (2)
2 BLK 0-6-2 18 AWG GXL N/A HV101 (2)
2 BLK 0-6-3 18 AWG GXL N/A HV105 (2)
S156
CONNECT OR PART NUM BER: SPLICE
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
T ERM INAL
P/N
T O
1 BLK 0-11 16 AWG GXL N/A CO02-J2 (6)
2 BLK 0-11-1 18 AWG GXL N/A HV109 (2)
2 BLK 0-11-2 18 AWG GXL N/A HV103 (2)
HV314
CHASSIS ENABLE
CONNECT OR PART NUM BER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
T ERM INAL
P/N
T O
1 WHT 55-31 CHS ENABLE 18 AWG GXL 4460465 CO02-J2 (2)
2 BLK 0-36 18 AWG GXL 4460465 CO02-J2 (17)
HV104
MAIN DUMP
CONNECT OR PART NUM BER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
T ERM INAL
P/N
T O
1 WHT 50-1 M AIN DUM P 18 AWG GXL 4460465 CO02-J2 (13)
2 BLK 0-10-2 18 AWG GXL 4460465 S154 (2)
HV106
MAIN LIFT UP
CONNECT OR PART NUM BER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T ERM INAL
P/N
T O
1 WHT 3-2 M LIF T UP 18 AWG GXL 4460465 CO02-J2 (11)
2 BLK 0-6-1 18 AWG GXL 4460465 S155 (2)
HV100
SWG LFT
CONNECT OR PART NUM BER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
T ERM INAL
P/N
T O
1 WHT 22-2 SWG LF T 18 AWG GXL 4460465 CO02-J2 (15)
2 BLK 0-30-1 18 AWG GXL 4460465 S153 (2)
HV109
MAIN TELE IN
CONNECT OR PART NUM BER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET
T ERM INAL
P/N T O
1 WHT 13-4 M T ELE IN 18 AWG GXL 4460465 CO02-J2 (4)
2 BLK 0-11-1 18 AWG GXL 4460465 S156 (2)
Figure 7-57. Hydraulic Valve Bank Harness - Sheet 3 of 3
