SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
3121619 – JLG Lift – 7-35
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 27-3 JIB DN O/R 18 AWG GXL X81 (15)
2 WHT 25-6 PLVL UP O/R 18 AWG GXL X81 (9)
3 WHT 25-5 PLVL DN O/R 18 AWG GXL X81 (7)
4 WHT 50-2 PLTFM DUMP 16 AWG GXL X341A (4)
5 WHT 50-3 JIB DUMP 16 AWG GXL X341A (3)
6 WHT 49-45 HYD OIL TEMP 18 AWG GXL CO02-J1 (35)
7 BLK 0-31 18 AWG GXL CO02-J1 (27)
8
9
10
11
BLK 0-14 18 AWG GXL X237 (1)
12 WHT 47-6 ALT EXC 18 AWG GXL S371 (2)
S372
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 YEL 2-1-99 IGNITION 16 AWG GXL RL235-R (1)
2 YEL 2-1-99 IGNITION 18 AWG GXL X218A (1)
2 YEL 2-1-99 IGNITION 18 AWG GXL X217A (1)
X217A
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 YEL 2-1-99 IGNITION 18 AWG GXL S372 (2)
2 BLK 0-17 16 AWG GXL CO02-J1 (8)
3 WHT 52-9 GEN 18 AWG GXL CO02-J1 (22)
4 WHT 48-7 GLOW 18 AWG GXL CO02-J1 (12)
5 YEL 2-13 16 AWG GXL RL235-R (1)
6 BLK 0-18 18 AWG GXL CO02-J1 (9)
7 WHT 48-8 SP 18 AWG GXL CO02-J1 (7)
8
X218A
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 YEL 2-1-99 IGNITION 18 AWG GXL S372 (2)
2 WHT 48-6 STRT 18 AWG GXL CO02-J1 (11)
3 YEL CAN HI 20 AWG J1939 CABLE MS83 (1)
4 GRN CAN LO 20 AWG J1939 CABLE MS83 (3)
5 WHT 47-6-1 ALT EXC 18 AWG GXL S371 (2)
6 SHLD CAN SHLD 20 AWG J1939 CABLE MS83 (5)
S371
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 47-6-2 ALT EXC 18 AWG GXL CO02-J1 (32)
2 WHT 47-6 ALT EXC 18 AWG GXL X159B (12)
2 WHT 47-6-1 ALT EXC 18 AWG GXL X218A (5)
S239
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 BLK 0-19 16 AWG GXL X362 (1)
2 BLK 0-19-1 18 AWG GXL X327B (6)
2 BLK 0-19-2 18 AWG GXL X84 (1)
Figure 7-40. Turntable Wiring Harness - Sheet 4 of 9
