SECTION 6 - JLG CONTROL SYSTEM
6-16 – JLG Lift – 3121619
PLATFORM
ROTATE: ACCEL X.Xs Displays/adjusts basket rotate acceleration 0.1 to 5.0 sec 1
DECEL X.Xs Displays/adjusts basket rotate deceleration 0.1 to 3.0 sec 0.5
MIN LEFT XX% Displays/adjusts minimum basket rotate left
speed. Same as Creep speed 0 to 100% 60
MAX LEFT XXX% Displays/adjusts maximum basket rotate left
speed 0 to 100% 60 15-20 (180
)
MIN RIGHT XX% Displays/adjusts minimum basket rotate right
speed. Same as Creep speed 0 to 100% 60
MAX RIGHT XXX% Displays/adjusts maximum basket rotate right
speed 0 to 100% 60 15-20 (180
)
JIB LIFT: ACCEL X.Xs Displays/adjusts jib lift acceleration 0.1 to 5.0 sec 1.5
DECEL X.Xs Displays/adjusts jib lift deceleration 0.1 to 3.0 sec 1
MIN UP XX% Displays/adjusts minimum jib up speed. Same
as Creep speed 0 to 65% 46
MAX UP XXX% Displays/adjusts maximum jib up speed 0 to 100% 65 70-120
MIN DOWN XX% Displays/adjusts minimum jib down speed.
Same as Creep speed 0 to 65% 46
MAX DOWN XXX% Displays/adjusts maximum jib down speed 0 to 100% 76 65-100
JIB SWING: ACCEL X.Xs Displays/adjusts jib swing acceleration 0.1 to 5.0 sec 1.5
DECEL X.Xs Displays/adjusts jib swing deceleration 0.1 to 3.0 sec 0.5
MIN LEFT XX% Displays/adjusts minimum jib left speed. Same
as Creep speed 0 to 65% 48
MAX LEFT XXX% Displays/adjusts maximum jib left speed 0 to 100% 70 60-68 (180
)
MIN RIGHT XX% Displays/adjusts minimum jib right speed.
Same as Creep speed 0 to 65% 55
MAX RIGHT XXX% Displays/adjusts maximum jib right speed 0 to 100% 70 60-68 (180
)
JIB TELESCOPE: ACCEL X.Xs Displays/adjusts jib tele acceleration 0.1 to 5.0 sec 1.5
DECEL X.Xs Displays/adjusts jib tele deceleration 0.1 to 3.0 sec 1
MIN IN XX% Displays/adjusts minimum jib tele in speed.
Same as Creep speed 0 to 65% 45
MAX IN XXX% Displays/adjusts maximum jib tele in speed 0 to 100% 70 20-25 (see orientation)
MIN OUT XX% Displays/adjusts minimum jib right speed.
Same as Creep speed 0 to 65% 40
MAX OUT XXX% Displays/adjusts maximum jib right speed 0 to 100% 70 20-25 (see orientation)
Table 6-4. Machine Personality Settings and Function Speeds
SUBMENU
(DISPLAYED ON
ANALYZER 1ST LINE)
PARAMETER
(DISPLAYED ON ANALYZER 2 ND
LINE)
DESCRIPTION RANGE
DEFAULT
VALUES
TIME RANGE
(SEC)
