SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
7-38 – JLG Lift – 3121619
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 RED 1-5 16 AWG GXL IP415 (1)
2 RED 1-4-1 18 AWG GXL CO02-J7 (3)
3 RED 1-4-3 18 AWG GXL X81 (5)
4 RED 1-4-2 18 AWG GXL IP91 (2)
5 YEL 2-12 18 AWG GXL X353 (1)
6 BLK 0-19-1 18 AWG GXL S239 (2)
7 GRN CAN LO 20 AWG J1939 CABLE MS82 (3)
8 YEL CAN HI 20 AWG J1939 CABLE MS82 (1)
9 WHT 49-46M CNTRL 18 AWG GXL CO02-J7 (21)
10
11
12
X412
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 BLK 0-22 14 AWG GXL X375 (1)
2 YEL 2-10 14 AWG GXL RL236-Y (1)
3 BLU CABLE 18 AWG CABLE CO02-J7 (12)
4 BLK CABLE 18 AWG CABLE CO02-J7 (19)
5 RED CABLE 18 AWG CABLE CO02-J7 (32)
6 SHIELD BRKN CBL PROX 18 AWG SHLD S469 (2)
MS83
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 YEL CAN HI 20 AWG J1939 CABLE X218A (3)
2
3 GRN CAN LO 20 AWG J1939 CABLE X218A (4)
4 GRN CAN LO 20 AWG J1939 CABLE X84 (4)
5 SHLD CAN SHLD 20 AWG J1939 CABLE X218A (6)
6 SHLD CAN SHLD 20 AWG J1939 CABLE S469 (2)
7 SHLD CAN SHLD 20 AWG J1939 CABLE X84 (5)
8
9
10 GRN CAN LO 20 AWG J1939 CABLE CO02-J12 (4)
11 YEL CAN HI 20 AWG J1939 CABLE X84 (3)
12 YEL CAN HI 20 AWG J1939 CABLE CO02-J12 (3)
MS82
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 YEL CAN HI 20 AWG J1939 CABLE X327B (8)
2 YEL CAN HI 20 AWG J1939 CABLE CO02-J7 (13)
3 GRN CAN LO 20 AWG J1939 CABLE X327B (7)
4 GRN CAN LO 20 AWG J1939 CABLE CO02-J7 (24)
5 SHLD CAN SHLD 20 AWG J1939 CABLE X81 (1)
6 SHLD CAN SHLD 20 AWG J1939 CABLE S469 (2)
7 SHLD CAN SHLD 20 AWG J1939 CABLE MS148-3 (C)
8
9 GRN CAN LO 20 AWG J1939 CABLE X81 (2)
10 GRN CAN LO 20 AWG J1939 CABLE MS148-3 (B)
11 YEL CAN HI 20 AWG J1939 CABLE X81 (3)
12 YEL CAN HI 20 AWG J1939 CABLE MS148-3 (A)
IP85
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 YEL 2-11-1 18 AWG GXL X84 (8)
2 YEL 2-11 18 AWG GXL CO02-J7 (34)
CO02-J1
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 55-30 LFT ENABLE 18 AWG GXL X440B (1)
2 WHT 55-35 AUX B+ DISC 18 AWG GXL RL360-85 (1)
3 WHT 27-6 J-UP O/R 18 AWG GXL X81 (13)
4
5
6
7 WHT 48-8 SP 18 AWG GXL X217A (7)
8 BLK 0-17 16 AWG GXL X217A (2)
9 BLK 0-18 18 AWG GXL X217A (6)
10
11 WHT 48-6 STRT 18 AWG GXL X218A (2)
12 WHT 48-7GLOW 18 AWG GXL X217A (4)
13 WHT 53-3 AUX PMP 18 AWG GXL RL127-86 (1)
14
15
16
17
18
19
20
21
22 WHT 52-9 GEN 18 AWG GXL X217A (3)
23 WHT 55-14 BRAKE 18 AWG GXL X147A (7)
24
25
26
27
BLK 0-31 18 AWG GXL X159B (7)
28 WHT 49-34 A-PWR 18 AWG GXL X88 (1)
29 WHT 49-35 A-RX 18 AWG GXL X88 (2)
30 WHT 49-36 A-TX 18 AWG GXL X88 (3)
31 WHT 49-37 A-GND 18 AWG GXL X88 (4)
32 WHT 47-6-2 ALT EXC 18 AWG GXL S371 (1)
33
34
35 WHT 49-45 HYD OIL TEMP 18 AWG GXL X159B (6)
X88
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 WHT 49-34 A-PWR 18 AWG GXL CO02-J1 (28)
2 WHT 49-35 A-RX 18 AWG GXL CO02-J1 (29)
3 WHT 49-36 A-TX 18 AWG GXL CO02-J1 (30)
4 WHT 49-37 A-GND 18 AWG GXL CO02-J1 (31)
CO02-J12
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1
2
3 YEL CAN HI 20 AWG J1939 CABLE MS83 (12)
4 GRN CAN LO 20 AWG J1939 CABLE MS83 (10)
5
6
WHT JUMPER 18 AWG GXL CO02-J12 (7)
7 WHT JUMPER 18 AWG GXL CO02-J12 (6)
8
Figure 7-43. Turntable Wiring Harness - Sheet 7 of 9
