SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
7-46 – JLG Lift – 3121619
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 61-1-4 5V 18 AWG GXL M S244 (3)
2 WHT 38-10 FAXS LF T 18 AWG GXL CO03-J1 (14)
3 BLK 00-8-2 18 AWG GXL S195 (2)
S181
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 BLK 00-1 18 AWG GXL CO03-J2 (14)
2 BLK 00-1-1 18 AWG GXL HV178 (2)
2 BLK 00-1-2 18 AWG GXL HV179 (2)
HV179 - BRAKE
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 55-14 BRAKE 18 AWG GXL CO03-J2 (13)
2 BLK 00-1-2 18 AWG GXL S181 (2)
SN423
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 WHT 49-71 HYD. OC RT N 18 AWG GXL CO03-J7 (32)
2 WHT 49-70 HYD. OC 18 AWG GXL CO03-J7 (12)
3
HV178 - TWO SPEED
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 55-13 2 SPD 18 AWG GXL CO03-J2 (1)
2 BLK 00-1-1 18 AWG GXL S181 (2)
X442A
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 WHT 61-1-1 5V 18 AWG GXL M S244 (7)
2 WHT 38-5 FAXS RHT 18 AWG GXL CO03-J2 (25)
3 BLK 00-2 18 AWG GXL CO03-J2 (6)
X338A
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 BLK RHT REAR ST R 18 AWG CABLE CO03-J7 (25)
2 RED RHT REAR ST R 18 AWG CABLE CO03-J7 (27)
3 BLU RHT REAR ST R 18 AWG CABLE CO03-J7 (20)
4 SHIELD SHLD 18 AWG SHLD S424 (2)
5
6
X340A
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 BLK RHT F RNT ST R 18 AWG CABLE CO03-J7 (9)
2 RED RHT F RNT ST R 18 AWG CABLE CO03-J7 (16)
3 BLU RHT F RNT ST R 18 AWG CABLE CO03-J7 (4)
4 SHIELD SHLD 18 AWG SHLD S424 (2)
5
6
S167
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 WHT 60-4 FAXS RT N 18 AWG GXL CO03-J3 (1)
2 WHT 60-4-1 FAXS RT N 18 AWG GXL HV161 (2)
2 WHT 60-4-2 FAXS RT N 18 AWG GXL HV162 (2)
S205
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 BLK 00-3 18 AWG GXL CO03-J2 (17)
2 BLK 00-3-1 18 AWG GXL HV170 (2)
2 BLK 00-3-2 18 AWG GXL HV171 (2)
S203
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 BLK 00-5 18 AWG GXL CO03-J2 (18)
2 BLK 00-5-1 18 AWG GXL HV174 (2)
2 BLK 00-5-2 18 AWG GXL HV175 (2)
HV161 - FRO NT AXLE SWG EXT.
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 38-2 FAXS EXT 18 AWG GXL CO03-J2 (4)
2 WHT 60-4-1 FAXS RT N 18 AWG GXL S167 (2)
HV171 - RIG HT FRO NT STR LFT
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 9-1 RF RNT ST RL 18 AWG GXL CO03-J2 (22)
2 BLK 00-3-2 18 AWG GXL S205 (2)
HV175 - RIG HT REAR STR LFT
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 WHT 9-6 RREAR ST RL 18 AWG GXL CO03-J2 (19)
2 BLK 00-5-2 18 AWG GXL S203 (2)
HV162 - FRO NT AXLE SWG RET.
CONNECT OR PART NUM BER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 38-3 FAXS RET 18 AWG GXL CO03-J2 (16)
2 WHT 60-4-2 FAXS RT N 18 AWG GXL S167 (2)
HV170 - RIG HT FRO NT STR RHT
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET T O
1 WHT 9-4 RF RNT ST RR 18 AWG GXL CO03-J2 (11)
2 BLK 00-3-1 18 AWG GXL S205 (2)
HV174 - RIG HT REAR STR RHT
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET T O
1 WHT 9-5 RREAR ST RR 18 AWG GXL CO03-J2 (8)
2 BLK 00-5-1 18 AWG GXL S203 (2)
Figure 7-51. Chassis Harness - Sheet 3 of 6
