SECTION 6 - JLG CONTROL SYSTEM
6-8 – JLG Lift – 3121619
Table 6-2. Machine Configuration Programming Information
Configuration Digit Number Description
Default
Number
NOTE: The machine configuration must be completed before any personality settings can be changed. Changing the personal-
ity settings first and then changing the model number of the machine configuration will cause the personality settings
to return to default
The items marked in BOLD bold text on this sheet represent a new board that has never been configured.
MODEL NUMBER:
1 0
1
2
No Model
1500SJ
1850SJ
0
ENVELOPE HEIGHT:
2 0
1
1500SJ: 150' MAX
1850SJ: 185’ MAX
0
Note: The default settings (bold) will vary depending on the model selection with selection # 5 being the initial default setting.
MARKET:
3 0
1
2
3
4
5
ANSI USA
ANSI EXPORT
CSA
CE
AUSTRALIA
JAPAN
0
ENGINE:
4 1
2
3
4
5
DEUTZ F4 TIER1: Deutz BF4M1011 Diesel (Tier 1)
DEUTZ F4 TIER2: Deutz BF4M2011 Diesel (Tier 2)
DEUTZ ECM: Engine Control Module
CAT Engine
DEUTZ ECM T4F: Engine Control Module (Tier 4 Final)
3
GLOW PLUG:
5 0
1
2
NO GLOW PLUGS: No glow plugs installed.
AIR INTAKE: Glow plugs installed in the air intake on the manifold.
IN-CYLINDER: Glow plugs installed in each cylinder.
2
STARTER LOCKOUT:
6 0
1
DISABLED: Automatic pre-glow time determined by ambient air temperature; engine start
can be attempted at any time during pre-glow.
ENABLED: Automatic pre-glow time determined by ambient air temperature; engine start is NOT permit-
ted until pre-glow is finished.
0
