JLG 1850SJ Service Manual - Manual (Page 399)

SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
3121619 – JLG Lift – 7-39
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 YEL 2-4-4 18 AWG GXL S89 (2)
2 YEL 2-4-3 18 AWG GXL S89 (2)
3 RED 1-4-1 18 AWG GXL X327B (2)
4 WHT 49-72 LIFT PRS 20 AWG GXL X440B (7)
5
6 WHT JUMPER2 18 AWG GXL CO02-J7 (17)
7 WHT 49-75 PRS CHK 20 AWG GXL X440B (4)
8 WHT 49-66 Y AXIS 18 AWG GXL X395 (4)
9 WHT 49-74 L P GND 20 AWG GXL X440B (6)
10 WHT 49-76 P C GND 20 AWG GXL X440B (3)
11 BLK B LNTH CBL 18 AWG CABLE SN123 (2)
12 BLU CABLE 18 AWG CABLE X412 (3)
13 YEL CAN HI 20 AWG J1939 CABLE MS82 (2)
14 YEL 2-5 18 AWG GXL X81 (11)
15 YEL 2-15 18 AWG GXL X81 (6)
16 WHT 49-73 L P PWR 20 AWG GXL X440B (5)
17 WHT JUMPER2 18 AWG GXL CO02-J7 (6)
18
19 BLK CABLE 18 AWG CABLE X412 (4)
20 WHT 49-65 X AXIS 18 AWG GXL X395 (3)
21 WHT 49-46 M CNTRL 18 AWG GXL X327B (9)
22
23 WHT JUMPER3 18 AWG GXL CO02-J7 (30)
24 GRN CAN LO 20 AWG J1939 CABLE MS82 (4)
25 BLK 0-60 18 AWG GXL X395 (2)
26 WHT 49-77 P C PWR 20 AWG GXL X440B (2)
27 WHT 49-64 TILT PWR 18 AWG GXL X395 (1)
28
29 WHT B LNTH CBL 18 AWG CABLE SN123 (4)
30 WHT JUMPER3 18 AWG GXL CO02-J7 (23)
31
32 RED CABLE 18 AWG CABLE X412 (5)
33
34 YEL 2-11 18 AWG GXL IP85 (2)
35 RED B LNTH CBL 18 AWG CABLE SN123 (1)
CO02-J8
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 BLK 0-20 12 AWG GXL X376 (1)
2 YEL 2-11 12 AWG GXL RL236-Y (1)
3 N/A UGM TO CHASSIS GND 4 AWG BRAID X467 (1)
4
X395
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 49-64 TILT PWR 18 AWG GXL CO02-J7 (27)
2 BLK 0-60 18 AWG GXL CO02-J7 (25)
3 WHT 49-65 X AXIS 18 AWG GXL CO02-J7 (20)
4 WHT 49-66 Y AXIS 18 AWG GXL CO02-J7 (8)
X468
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 N/A CAN SHIELD TO CHASSIS GND 4 AWG BRAID S469 (1)
S469
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 N/A CAN SHIELD TO CHASSIS GND 4 AWG BRAID X468 (1)
2 SHIELD BRKN CBL PROX 18 AWG SHLD X412 (6)
2 SHLD CAN SHLD 20 AWG J1939 CABLE MS83 (6)
2 SHLD CAN SHLD 20 AWG J1939 CABLE MS82 (6)
X467
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 N/A UGM TO CHASSIS GND 4 AWG BRAID CO02-J8 (3)
Figure 7-44. Turntable Wiring Harness - Sheet 8 of 9
