SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
7-48 – JLG Lift – 3121619
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 YEL CAN HI 18 AWG J1939 CABLE CO03-J7 (13)
2 GRN CAN LOW 18 AWG J1939 CABLE CO03-J7 (24)
3 SHLD CAN SHLD 18 AWG J1939 CABLE CO03-J7 (18)
4
5
6
7 WHT 55-14 BRAKE 18 AWG GXL CO03-J7 (15)
8
9
10
11 WHT 55-17 DOS 18 AWG GXL CO03-J7 (11)
12 YEL 02-4 18 AWG GXL CO03-J7 (29)
CO03-J1
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1
2
3
4
5
6
7
8 BLK 00-9 18 AWG GXL SN243 (E)
9 BLK 00-8 18 AWG GXL S195 (1)
10
11
12
13
14
WHT 38-10 FAXS LFT 18 AWG GXL X449B (2)
15 WHT 38-9 RAXS RHT 18 AWG GXL X448B (2)
16 WHT 55-15 TTABLE ANG 18 AWG GXL SN243 (C)
17
18 BLK 00-14 18 AWG GXL SN243 (A)
19
20
21
22
23
24
25
26
27
28
WHT 49-40 A-PWR 18 AWG GXL X160 (1)
29 WHT 49-39 A-RX 18 AWG GXL X160 (2)
30 WHT 49-38 A-TX 18 AWG GXL X160 (3)
31 BLK 00-7 18 AWG GXL X160 (4)
32
33
34
35
MS244
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 61-1-6 5V 18 AWG GXL SN243 (B)
2 WHT 61-1-5 5V 18 AWG GXL SN243 (F)
3 WHT 61-1-4 5V 18 AWG GXL X449B (1)
4 WHT 61-1-3 5V 18 AWG GXL X448B (1)
5
6 WHT 61-1 5V 16 AWG GXL CO03-J3 (12)
7 WHT 61-1-1 5V 18 AWG GXL X442A (1)
8 WHT 61-1-2 5V 18 AWG GXL X445A (1)
Figure 7-53. Chassis Harness - Sheet 5 of 6
