SECTION 7 - BASIC ELECTRICAL INFORMATION & ELECTRICAL SCHEMATICS
3121619 – JLG Lift – 7-21
MS262-3
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
A YEL CAN HI 20 AWG J1939 CABLE CO245-J4 (3)
B GRN CAN LOW 20 AWG J1939 CABLE CO245-J4 (4)
C SHLD SHIELD 20 AWG J1939 CABLE CO245-J4 (5)
X230A
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 SHLD SHIELD 20 AWG J1939 CABLE CO245-J1 (8)
2 GRN CAN LOW 20 AWG J1939 CABLE CO245-J1 (7)
3 YEL CAN HI 20 AWG J1939 CABLE CO245-J1 (6)
4 YEL 2-4 18 AWG GXL X228B (4)
5 RED 1-4-3 18 AWG GXL X228B (5)
6 YEL 2-15 18 AWG GXL X228B (6)
7 WHT 25-5 PLVL DN O/R 18 AWG GXL X228B (7)
8
9 WHT 25-6 PLVL UP O/R 18 AWG GXL X228B (9)
10 YEL 2-25 12 AWG GXL MS380 (7)
11 YEL 2-5 18 AWG GXL X228B (11)
12 YEL 2-26 12 AWG GXL MS380 (6)
13 WHT 27-6 J-UP O/R 18 AWG GXL CO245-J1 (2)
14
15 WHT 27-3 JIB DN O/R 18 AWG GXL CO245-J1 (1)
16 BLK 0-40 12 AWG GXL MS380 (10)
17
18 BLK 0-41 12 AWG GXL MS380 (3)
19
MS262-2
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
A YEL CAN HI 20 AWG J1939 CABLE SN260 (3)
B GRN CAN LOW 20 AWG J1939 CABLE SN260 (4)
C SHLD SHIELD 20 AWG J1939 CABLE SN260 (5)
X364B
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 RED 1-7-2 WK LT PWR 16 AWG GXL X365A (1)
2 RED 1-7-1 WK LT PWR 16 AWG GXL X365A (2)
3 WHT 50-3 JIB DUMP 16 AWG GXL HV248 (1)
4 WHT 50-2 PLTFM DUMP 16 AWG GXL X365A (4)
SN259
JIB TRANS 2
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 YEL 2-19 18 AWG GXL MS380 (9)
2 WHT 49-20 PROX NC 18 AWG GXL X228B (15)
3 BLK 0-27-1 18 AWG GXL S383 (2)
4 WHT 49-19 PROX NO 18 AWG GXL X228B (13)
MS262-1
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
A YEL CAN HI 20 AWG J1939 CABLE X228B (3)
B GRN CAN LOW 20 AWG J1939 CABLE X228B (2)
C SHLD SHIELD 20 AWG J1939 CABLE X228B (1)
SN258
JIB TRANS 1
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 YEL 2-21 18 AWG GXL CO245-J4 (7)
2 WHT 49-44 PROX 1NC 18 AWG GXL CO245-J2 (7)
3 BLK 0-24 18 AWG GXL CO245-J4 (8)
4 WHT 49-43 PROX 1NO 18 AWG GXL CO245-J2 (6)
HV256
JIB LVL UP
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 55-20 JLVL UP 18 AWG GXL CO245-J2 (11)
2 BLK 0-25-1 18 AWG GXL MS347 (8)
HV250
JIB SWG RHT
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 59-1-1 JSWG RT 18 AWG GXL CO245-J5 (3)
2 BLK 0-26-5 18 AWG GXL MS347 (2)
HV253
JIB LIFT DN
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 27-4-2 JIB DN 18 AWG GXL S265 (2)
2 BLK 0-26-2 18 AWG GXL MS347 (9)
HV248
JIB ENABLE
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 WHT 50-3 JIB DUMP 16 AWG GXL X364B (3)
2 BLK 0-47 16 AWG GXL S383 (2)
HV251
JIB TELE OUT
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 29-4-1 JIB OUT 18 AWG GXL CO245-J5 (6)
2 BLK 0-26-4 18 AWG GXL MS347 (3)
HV254
JIB LIFT UP
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 27-5-2 JIB UP 18 AWG GXL S264 (2)
2 BLK 0-26-1 18 AWG GXL MS347 (10)
SN246
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
A BLK GROUND 18 AWG CABLE CO245-J3 (12)
B RED 5V PWR 18 AWG CABLE CO245-J3 (10)
C BLU SIGNAL 18 AWG CABLE CO245-J3 (8)
D WHT SIGNAL 18 AWG CABLE CO245-J3 (11)
E GRN GROUND 18 AWG CABLE CO245-J3 (9)
F ORG 5V PWR 18 AWG CABLE CO245-J3 (7)
HV249
JIB SWG LFT
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 59-2-1 JSWG LT 18 AWG GXL CO245-J5 (4)
2 BLK 0-26-6 18 AWG GXL MS347 (1)
HV255
JIB LVL DN
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 55-19 JLVL DN 18 AWG GXL CO245-J2 (12)
2 BLK 0-25-2 18 AWG GXL MS347 (7)
SN247
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
A BLK GROUND 18 AWG CABLE CO245-J3 (6)
B RED 5V PWR 18 AWG CABLE CO245-J3 (4)
C BLU SIGNAL 18 AWG CABLE CO245-J3 (2)
D WHT SIGNAL 18 AWG CABLE CO245-J3 (5)
E GRN GROUND 18 AWG CABLE CO245-J3 (3)
F ORG 5V PWR 18 AWG CABLE CO245-J3 (1)
HV252
JIB TELE IN
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET TO
1 WHT 29-3-1 JIB IN 18 AWG GXL CO245-J5 (5)
2 BLK 0-26-3 18 AWG GXL MS347 (4)
SN257
CONN
POS
WIRE
COLOR
WIRE
LABEL GAUGE JACKET TO
1 YEL 2-22 18 AWG GXL CO245-J4 (1)
2 WHT 49-42 LOCK NC 18 AWG GXL CO245-J2 (5)
3 BLK 0-23 18 AWG GXL CO245-J4 (2)
4 WHT 49-41 LOCK NO 18 AWG GXL CO245-J2 (4)
Figure 7-26. Jib Valve Wiring Harness - Sheet 2 of 3
