Galaxy® CO2 Sensor Setup — Instructions
1 Galaxy 170 R / 48 R 120 V / 230 V CO 2 Incubators
1 Galaxy 170 R / 48 R 120 V / 230 V CO
2
Incubators
1.1 K1 CO
2
Sensor update kit retro fit instructions
Parts Supplied
1 CO
2
Sensor with Flying Leads and Connector Block
1 Porous Sensor Cover, Sintered
1 Bracket Strain Relief
6 Washer, M3 Spring, A2 Stainless Steel
3 M3 Washer
3 M3 Nut
3 M3 detector spacer 3.18 mm ID x 7 mm
2 Cable Tie, 2.5 x 100 Long
1 Nut M4
1 Spacer 9.53 x 12.7 Long
1 Cable Tie Mount
1 M4 x 20 Pozidriv Screw
1 Spring, Tube Support
1 Solenoid Valve Assembly 24 VDC
1 Equipment Tray Cover Panel
1.3 m Tube, Silicone Rubber, Clear
2 M4 Washers
2
M4 x 6 Pozidriv ® Screws
12 Cable Tie, 2.5 x 100 Long
1 Bracket Self Adhesive Solenoid Valve
2 Self Adhesive Pads
1 IPA Cleaning Pad
1 Galaxy R-Plus Board 'Two'
2 EPROM ( Updated For Auto-Zero 1 off each model)
1
Galaxy 170 R / 48 R 120 V / 230 V CO
2
Incubators
