Galaxy® CO2 Sensor Setup — Instructions
2 Galaxy 170 S 230 V / 120 V CO 2 Incubators
2 Galaxy 170 S 230 V / 120 V CO
2
Incubators
2.1 K2 CO
2
Sensor update kit retro fit instructions
Parts Supplied
1 CO
2
Sensor with Flying Leads and Connector Block
1 Porous Sensor Cover, Sintered
1 Bracket Strain Relief
6 Washer, M3 Spring, A2 Stainless Steel
3 M3 Washer
3 M3 Nut
3 M3 detector spacer 3.18 mm ID x 7 mm
2 Cable Tie, 2.5 x 100 Long
1 Nut M4
1 Spacer 9.53 x 12.7 Long
1 Cable Tie Mount
1 M4 x 20 Pozidriv Screw
1 Spring, Tube Support
1 Solenoid Valve 230 VAC or 120 VAC Assembly
1 Equipment Tray Cover Panel
1.3 m Tube, Silicone Rubber, Clear
2 M4 Washers
2 M4 x 6 Pozidriv Screws
20 Cable Tie, 2.5 x 100 Long
1 PCB Assembly with bracket plate
3 M3 Washers
3 M3 x 12 Cheese Head, Stainless
3 Detector spacer, 3.18 mm ID x 7
1 5 V Miniature Diaphragm Pump
0.6 m Brown 18 AWG UL1015 105 DegC with Female Crimp Spade Terminal
4 M3 x 6 Pozidriv Screw
6 Large Cable Tie, 3.5 mm . 300 mm long
6 Large Cable Tie Base, 27 mm x 27 mm
