Galaxy® CO2 Sensor Setup — Instructions
22
Door Harness Connectors
Solenoid Pump Valve PCB bracket mounting points
11. Mount the PCB/bracket in the tray as shown in the image below using the screws supplied to
secure in position then route the wiring along the back of the Equipment Tray.
2
Galaxy 170 S 230 V / 120 V CO
2
In
cubators
