Biological Shakers Innova® 44/44R — Operating manual
46
2. Turn the Knob until the field says New. Click the Knob in to select this mode. The screen for
Program 1 - Step 1 will open (see Fig. 30 on p. 46):
Abb. 30: Program 1, Step 1
Fig. 30: Program 1, Step 1
3. Turn the Knob to highlight the Time setting (00:00 in the sample screen above), then click the
Knob in. The field will flash.
4. Turn the Knob until the desired running duration for this step (from 00:01, which means one
minute, to 99:59) appears, then click the Knob in to save the setting. We will set Step 1 time to
eight hours for this example (see Fig. 31 on p. 47).
5. Turn the Knob to highlight the °C temperature setting (20.0 in the sample screen above), then
click the Knob in. The field will flash.
6. To set the temperature desired (°C from 4.0 to 80.0) for the time period you have set, turn the
Knob (left to decrease, right to increase). When the desired value appears, click the Knob in
to save the setting. We will set Step 1 temperature to 37.0 °C (see Fig. 31 on p. 47).
7. Turn the Knob to highlight the RPM setting (Off in the sample screen above), then click the
Knob in. The field will flash.
8. Turn the Knob to select the desired shaking speed (25 to 400 RPM) for this time period, then
click the Knob in to save the setting. We will set Step 1 speed to 150 RPM (see Fig. 31 on
p. 47).
9. If you do not have the optional UV lamp, skip this step. If you have the UV lamp (default
setting is Off) and you wish to have it on during the time period you have set, use the Control
Knob to select the field, click the Knob to select the field (it will flash), turn the Knob to select
On, then click the Knob in to save the setting. In our sample Step 1 (see Fig. 31 on p. 47),
however, UV remains Off.
10. If you do not have the optional GRO lamps, skip this step. If you have the photosynthetic
lamps (default setting is Off) and you wish to have them on during the time period you have
1 Step Number 2 Use to leave programming mode without saving
any new settings.
3 Do not use until programming is complete. 4 Use these arrows to scroll through steps.
PRG1 - STEP -- 01
Time 00:00
ºC 20.0
RPM Off
UV Off
GRO Off
Save Cancel
1
2 3
4
Hint!
If your shaker is not equipped with these optional features, “UV” and “GRO” will appear with the
word “Off” in this screen but will not be programmable.
