Biological Shakers Innova® 44/44R — Operating manual
42
To move out of this screen and into the next:
1. Use the control Knob to highlight SET, then click the Knob in.
SET begins to flash.
2. Turn the Knob to the right until the next screen, Lamps (LAMP), appears. If you turn too far
and enter another screen, just turn the Knob back to the left to recapture the LAMP screen.
3. Click the Knob in to select the screen and to work in it.
9.4.4 Lamps screen
In this screen (see Fig. 25 on p. 42), you can turn the chamber light (Chamber), the optional UV
germicidal (“decontamination”) lamp (UV Decont) and the optional photosynthetic growth lamps
(Growth) on and off. On means the light is always on, and Off means the light is always off,
unless you add additional programming (see Program the shaker on p. 45).
There is an additional mode for the chamber light: Auto. In Auto mode, the light will go on every
time you activate the control knob or open the door. This is the default mode.
Abb. 25: Lamps Screen
Fig. 25: Lamps Screen
To change the mode setting for any of the lamps:
1. Turn the Control Knob to highlight the setting for the lamp of choice, then click the knob in.
The current setting will flash (in the sample screen, we will use the Chamber light as an
example.
2. Turn the Knob left or right until the desired mode setting appears (Auto in this example).
3. Click the Knob in to save the new setting.
To move out of this screen and into the next:
1. Use the Control Knob to highlight LAMP, then click the Knob in.
LAMP begins to flash.
2. Turn the Knob to the right until the next screen, RS232 (COMM), appears. If you turn too far
and enter another screen, just turn the Knob back to the left to recapture the COMM screen.
3. Click the Knob in to select the screen and to work in it.
Hint!
The Lamps screen, shown below, will always indicate Chamber light mode. If the shaker is not
equipped with the optional UV germicidal lamp and/or photosynthetic growth lamps, UV Decont
and/or Growth will say None.
LAMPS
Chamber : Auto
UV Decont : Off
Growth : Off
LAMP Th 16:20
Hint!
If you highlight an item, change it, but do not save your selection, after a few seconds the screen
will revert to its previous setting.
