Biological Shakers Innova® 44/44R — Operating manual
36
Abb. 19: Front Grille
Fig. 19: Front Grille
2. Check the drain hose to be sure it is clamped tightly.
3. Replace the grille and secure it with the four thumbscrews and the washers that you
previously removed.
4. Accessing the pan/reservoir from the left, the right or in front of the subplatform, slowly fill the
reservoir with no more than 3 liters of distilled water.
8.10 Drain the water reservoir
To drain water from the water reservoir/spill pan:
1. Temporarily remove the four thumbscrews that secure the front grille (see Fig. 19 on p. 36).
2. Disengage the drain hose, direct it to a container or drain, then unclamp it, allowing the water
to gravity drain.
3. Reclamp the hose, tuck it back in place, and replace the grille, securing it with the
thumbscrews you previously removed.
1 Front Grille 2 Drain Hose - extends through this cutout
1
2
Hint!
Never pour water directly under the subplatform. Pour water very slowly into the shallow area
beyond the edge of the adapter plate, to protect the bearing housing.
Hint!
The spill pan/water reservoir drain is located in the front, on the left, under the slide-out tray.
Hint!
The drain hose should be tightly clamped when it is not being used for draining the reservoir.
Keep it clamped even if there is no water in the pan.
