Biological Shakers Innova® 44/44R — Operating manual
Abb. 22: Changing Setpoint
Fig. 22: Changing Setpoint
3. Turn or spin the Knob to reset the setpoint (in this example, turn the Knob left to decrease the
setpoint to 37.0).
4. Click the Knob in to set and save this new setpoint.
5. The display will automatically return to the actual value.
To move out of this screen and into the next:
1. Use the Control Knob to highlight DISP, then click the Knob in.
DISP begins to flash.
2. Turn the Knob to the right until the next screen, Summary (SUMM), appears. If you turn too
far and enter another screen, just turn the Knob back to the left to recapture the SUMM
screen.
3. Click the Knob in to select the screen and to work in it.
9.4.2 Summary screen
In this screen (see Fig. 23 on p. 40), you can see both the current ACTUAL readings and the
SET points for shaking speed (RPM), chamber temperature (°C), elapsed time in a programmed
run (HRS) and, if you are using the optional Humidity Monitor, the percentage of relative humidity
(%RH).
ºC 38.5
RPM 120
DISP We 13:44
Hint!
If you turn the Control Knob slowly, one click left or right will change the setpoint by an increment
of one tenth of a degree Celsius (0.1 °C). If you spin the Knob quickly, the value will change by
larger increments.
Hint!
If you highlight an item, change it, but do not save your selection, after a few seconds the screen
will revert to its previous setting.
9
Operation
