9
2 Device description
Variable regulator
In the normal operating mode, the parameters for injection are set by the
three variable regulators. The arrangement of the variable regulators
corresponds to the arrangement of the parameters in the two bottom lines
of the display:
From left to right: injection pressure pi, injection time ti and compensation
pressure p
c
.
In other operating modes, the variable regulators have either the
significance indicated in the display or no significance at all.
Tube connection
The injection tube is connected to the device via a bayonet joint.
