6036/6036T
Figure 55A
OA1091
10 amp
7.5 amp
20 amp
40 amp
7.5 amp
10 amp
1
10 amp
Enclosed Cab Windshield
(Fuse)
Washer/Wiper Switch and
Circulation Fan (Optional this
fuse will not be found on vehicles
with an open cab)
2
7.5 amp
Steering Select Switch and
(Fuse)
Valve
3
10 amp
Horn and Back-up Alarm
(Fuse)
(Optional - Cab Heater Fan)
4
7.5 amp
Warning Lights, Emergency
(Fuse)
Brake Solenoid Switch, Fuel
Gauge and Hourmeter
5
20 amp
(Optional - Lighting Package)
(Fuse)
6
40 amp
Ignition Switch Feed For Entire
(Breaker)
Electrical System
Index
Size
Circuit Protected
The following fuses/circuit breaker are used (Figure 55A):
1
2
3
4
5
6
FOR VEHICLES WITH FUSES/CIRCUIT BREAKER
