Page 28
6036/6036T
2. Four Wheel Steering (See Figure 12)
Warning
NEVER use the four wheel steer mode when
traveling at high speed. Rapid turning in this mode
will cause tipover. Use only the two wheel steer
mode at high speeds and slow the vehicle when
turning.
Figure 12 OH0070
The front wheels will steer in the direction that the
steering wheel is turned; the rear wheels will steer
in the opposite direction. This mode allows an
extremely short turning radius. It also enables the
rear wheels to follow the tracking of front wheels
which is an advantage in mud or sand conditions.
OH0080
Figure 13
3. Two Wheel Steering (See Figure 13)
The front wheels will steer in the direction that the
steering wheel is turned. The rear wheels will
remain in the fixed forward position. This mode is
used for on-highway travel or at higher speeds.
