Page 69 6036/6036T
3. Place a small pan or receptacle under the trans-
mission filter (Figure 46) to catch fluid when the
filter is removed.
4. Remove the old filter element with a strap or
chain wrench. Discard element.
5. Apply a thin film of clean MIL-L-2104C Oil (See
table on page 68) to the new element gasket.
TRANSMISSION FILTER
TRANSMISSION
DIPSTICK
OA0402
Figure 46
B. Filter Change (1000 Hours Intervals or Annually)
1. Level the vehicle, ground the carriage, place travel
select lever in (N) Neutral, engage the emergency
brake switch and shut off the engine.
2. Remove the transmission cover from the top of
the frame.
6. Turn new element onto transmission fitting.
Torque element to 20 - 25 lb-ft (27 - 34 Nm) .
7. Remove and discard drained fluid.
8. Check transmission level and add MIL-L-2104C
Oil (See table on page 68.) as required following
procedures in paragraph 8A.
9. Install transmission cover on frame.
C. Oil Change (1000 Hour Intervals or Annually)
1. Level the vehicle, ground the carriage, place
travel select lever in (N) Neutral, engage the
emergency brake switch and shut off engine.
2. Place a funnel with flexible drain under the
transmission sump housing (Figure 47) and a
receptacle to catch fluid.
3. Remove sump plug/screen with gasket
(Figure 47) and allow transmission to drain
completely. Discard gasket. Dispose of used oil
at an approved recycling facility.
4. Clean plug/screen thoroughly using a standard
solvent.
5. Install new filter element by following procedures
in paragraph 8B, but, DO NOT start engine at this
time.
6. Install cleaned drain plug/screen with new gasket
in transmission sump housing. Discard old fluid.
