Page 66
6036/6036T
C. Oil Change
Change hydraulic oil filter after the first 50 hours
of operation and every 1000 hours or annually
thereafter.
Replace hydraulic oil annually or as required. Oil
must be cool before changing.
Other than the annual interval, the hydraulic oil must
be changed when a hydraulic component has con-
taminated the system.
1. Level the vehicle, ground the carriage, place travel
select lever in (N) Neutral, engage the emergency
brake switch and shut off the engine.
4. The oil level should be visible within 1/2 inch of the
upper mark on the sight gauge. If it is not, open
the locked hydraulic fill access door (Figure 43).
Remove the reservoir cap and add ISO-46 or MIL-
L-2104C oil. (See table on page 65.) For vehicles
equipped with the original sight gauge, the hydrau-
lic oil level should be up to the minimum oil level
line on the adjacent decal.
5. Install reservoir cap, close and lock fill access
door.
Figure 43
OA1040
ORIGINAL
HYDRAULIC OIL TANK
SIGHT GAUGE
HYDRAULIC FILL
ACCESS DOOR
NEW
SIGHT
GAUGE
2. Level the vehicle, ground the carriage, place travel
select lever in (N) Neutral, engage the emergency
brake switch and shut off the engine.
3. Check level of hydraulic oil in tank at the sight gauge
on the right side of the main frame (Figure 43).
2. Remove the hydraulic tank access cover. Clean
area around filter head.
3. Unscrew the nuts (Figure 44) that secure the filter
head to the hydraulic tank.
4. Remove the filter head, element and gasket from
the tank.
Warning
DO NOT change the hydraulic oil filter with the engine
running. Contact with moving parts can cause serious
injury or death.
