Page 16 6036/6036T
OA0071
SEAT
BELT
FORWARD/
BACKWARD
LEVER
HEATER
CONTROL CAB HEATER
SUSPENSION
ADJUST KNOB
Windshield Washer/Wiper Control
(Enclosed Cab Only)
Turn the knob counterclockwise to operate the wipers at
low speed; turn the knob clockwise to operate the
wipers at high speed. Pressing the knob activates the
windshield washer for as long as it is held in. The
windshield washer fluid tank is located to the rear of the
right console.
Door Latches ( Enclosed Cab Only)
(Not Pictured)
There are two door latches. The outside latch is a key
lockable pull to release type. The inside latch is either a
push to release or a pull to release type.
Cab Heater (Enclosed Cab Only)
(See Figure 5)
The cab heater fan is only operable when the ignition
switch is in the RUN position. The heater fan switch is
located on the left side of the seat base (Figure 5). The
switch has three positions: OFF, LO, and HI.
NOTE: During warm weather operation, close the
heater line shut-off valve, located in the heater hose
connection at the engine. (Valve is above alternator on
Perkins and below alternator on Cummins. Both are
near the left rear of the engine.)
Figure 5
Roof Washer/Wiper Control
(Enclosed Cab Only) (Not Pictured)
The roof wiper is a single speed wiper. Turn the knob
clockwise one position to operate the wiper. Pressing
the knob activates the roof washer for as long as it is
held in. The washer fluid tank is the rear tank located
next to the seat support.
