Page 17 6036/6036T
Seat Belt (See Figure 5)
The seat belt has a slide on each strap that is used to
tighten and loosen the strap on each side of the buckle.
To shorten, pull bottom of loop toward buckle. To
lengthen, hold slide strap, pull slide toward buckle and
readjust buckle on loop. Buckle the two straps together
to fasten. Lift the buckle latch or press the center button
to unfasten the seat belt.
Operator's Seat Adjustment (See Figure 5)
The position and suspension of the operator's seat can
be adjusted.
Suspension — Turn the knob on the front of the seat to
adjust suspension stiffness for operator weight.
Instruments/Indicators
There are four warning lights in a cluster between the
hourmeter and fuel gauge. When the ignition switch is
turned to the RUN position the Engine Oil Pressure and
Alternator Charge indicators will light up. This is a normal
condition. While the engine is running, all lights should be
OFF. However, if any of the lights turn ON an abnormal
condition exists. These conditions are:
Warning Lights (See Figure 6)
OH0371
ENGINE OIL
PRESSURE
LIGHT
TRANSMISSION/
HYDRAULIC OIL
TEMPERATURE
LIGHT
ALTERNATOR
CHARGING
LIGHT
ENGINE WATER
TEMPERATURE
LIGHT
• Engine Water Temperature Light
Indicates high engine coolant temperature.
• Engine Oil Pressure Light
Indicates low engine oil pressure.
• Alternator Charging Light
Indicates alternator is not charging.
• Transmission/Hydraulic Oil Temperature Light
Indicates high transmission or hydraulic oil temperature.
Height — Height adjustment is achieved by grasping the
bottom of the seat and raising upward into one of the
three detent positions. Once the seat has reached the
highest detent position, it can be lowered by raising the
seat all the way and lowering it fully. The seat can then
be raised, one detent at a time to the desired height.
Forward/Backward — Release the lever on the left side
of the seat and slide seat forward or backward to suit.
