Page 13 6036/6036T
EMERGENCY BRAKE
P
P
Travel Select Lever (See Figure 2)
The travel select lever has three positions to select
direction of travel:
F = Forward ........ all the way up
N = Neutral ......... center position
R = Reverse ....... all the way down
When the travel select lever is shifted into reverse, the
back-up alarm will automatically sound.
NOTE: The travel select lever must be in NEUTRAL to
permit engine starting.
Emergency Brake Switch (See Figure 2)
The emergency brake switch has two positions:
Engaged ............... lift red switch cover then
push switch up
Disengaged .......... lower red switch cover
The emergency brake must be ENGAGED to permit
engine starting. Operator should use caution when
engaging the emergency brake while the vehicle is
moving, because the stop will be abrupt and operator
may be jolted forward unexpectedly. The emergency
brake may be used to stop in an emergency situation.
Steering Select Switch (See Figure 2)
This switch has three positions:
Four Wheel Steer .... up position
Two Wheel Steer ..... center position
Crab Steer ............... down position
Refer to Steering under "Operating" for detailed information.
P
P
OG0390
EMERGENCY
BRAKE SWITCH
TRAVEL SELECT
LEVER
STEERING
SELECT SWITCH
RANGE
SELECT LEVER
OH0044 Figure 2
OH0780
HORN BUTTON
