❑ Introduction
22 Pump Ends
p/n: 029-0020-61-0
NOTICE !
PERFORMANCE OF PUMP END PUMPING SYSTEMS MEET OR EXCEED
NFPA 1921 REQUIREMENTS. FOR COMPLETE NFPA 1921 COMPLIANCE,
THE PUMPING UNITS MUST BE MARKED WITH SPECIFIC LABELS. CON-
SULT FACTORY IF THESE LABELS ARE REQUIRED.
2.2 PUMPING SYSTEM OVERVIEW
❑ Typical 20FS Series — see Figure 2-2: “Typical 20FS Series Pump Sys-
tem Overview” on page 23.
❑ Typical 30FS Series — see Figure 2-3: “Typical 30FS Series Pump Sys-
tem Overview” on page 24.
❑ Typical 40 / 50FB Series — see Figure 2-4: “Typical 40 / 50FB Series
Pump System Overview” on page 25.
❑ Typical FB50 / FB75 / FB100 Series — see Figure 2-5: “Typical FB50,
FB75 and FB100 Series Engine Mount Pump End Overview” on page
26.
❑ Typical 60FB / 60FJ Series — see Figure 2-6: “Typical 60FBG Series
Pump System Overview” on page 27.
❑ Typical 80FC / 80FCG Series — see Figure 2-7: “Typical 80FC Series
Pump System Overview” on page 28.
❑ Typical Check Valve Option, Discharge — see Figure 2-9: “Check
Valve Option, Discharge” on page 30.
